HDE Range – Heavy Duty Emergency Telephones

The HDE Range represents Guardian’s line of versatile Heavy Duty Emergency Telephones, designed to provide a reliable two-way link for emergency, access, or information assistance in challenging environments. Available in both analog (HDE) and VoIP (HDE-V) configurations, these units are engineered to withstand vandalism, moisture, dust, and corrosive chemicals.

Built to Withstand
The HDE Range offers various models for recessed or wall-mount installations, featuring single emergency buttons or combined call buttons and 12-digit keypads. This makes them ideal for a wide array of applications—from universities and public access areas to industrial parks and transit facilities.

Key Features & Benefits

VoIP Sitara Class Control Module
• The new OS with web interface to support product configuration easier with logs and status bars. Enhanced self-diagnostics. Interactive help.
• Supports the latest security protocols (ie: TLS1.2) while still maintaining backwards compatibility.
• SSL Certificates are supported. Web Interface Screen for SSL. Allows import of web, client and auto provisioning Client Certificates.
• Compatible with SIP-based IP-PBX servers that comply with SIP (RFC 3261).
• "Full" duplex operation.
• PoE 802.3af, 802.3at & 802.3bt enabled (Power-over-Ethernet) or alternate power source (24VDC).
• Full duplex voice w/adaptive echo canceling.
• Auxilliary Relay to control external devices with multiple control modes.
• Network web management interface.
• Real-Time monitoring with iGuard (iGuard is an encrypted, on prem or cloud-based platform that allows you to configure, monitor and maintain deployed Guardian endpoints).
• HDE-V models with an "Emergency" push button – depressing the button once automatically rings a designated number to summon help.
• HDE-V models with a keypad can be configured for manual dialing.
• Night ringer mode – refer to product manual.
• 316 Stainless Steel – 16 Gauge with #4 Brushed Finish, corrosion resistant enclosures
• LED – The call switches have integrated LEDs which can be configured for automatic or manual operation under multiple conditions.
• Speaker Output Power: 7W can exceed 90dB.
• ADA (American Disability Act) & Ontarians with Disabilities Act (AODA) compliant and labeled.
• Operating temp: -40˚ to +140˚F ( -40˚ to +60˚C ).
• Supports CISCO SRST (User selectable) / Supports Mitel Resiliency (User Selectable).
• Easy bolt on module for high power internal/external hearing loop T-Coil Amplifier.
• VoIP Expansion Module - 802.3BT compliant POE for single LAN cable connection to both expansion module and VoIP Controller.
