What is the real difference between analog camera resolution and HD-CVI or IP Megapixel resolution?

Posted by

Bookmark and Share

Analog resolutions are usually referred to in TVL (TV Lines).  420 TVL, 480 TVL, 540 TVL, 600 TVL, 700 TVL, 1000 TVL - What are TV-Lines really?  It is easier to see the difference between analog and mega-pixel using a picture showing the same scene at different resolutions.

Resolution of Megapixel Cameras

The QVGA image is 1,228,800 megapixels just less than the 1.3mp or 720P.  By comparison a 700TVL camera has about 480,000 pixels.

The 1.3mp is 3X the quality of a 700TVL camera and the 2mp is about 5X the resolution.

Our HD-CVI and IP systems are both now 1.3 or 2mp and the IP system will have 4mp cameras available very soon.

These resolutions give a wider viewing area and allow greater distortion free digital zoom.

Bookmark and Share

View Comments

What is USB-C

What Is USB-C? USB-C is the new industry standard connector and cable used for connectivity and power.Why do we need it? The new laptops are so thin that they have no space for older USB type connectors.  The good thing about USB-C is there is no top or bottom orientation. Just line it up and you are good to [...]

Read More »

​ Low Voltage Mounting Ring Template and Level

Low Voltage Mounting Bracket TemplateThis simple mounting template should be in every tool box. Easily mark out a level cutting line for installing caddy fasteners and Arlington LV1's. Simply use your drywall jab saw to cut along the line and you will have straight level plates from now on.

Read More »

New Tech Industries Holiday Party

New Tech Industries invited all local customers to come in for hot dogs, Jamaican patties and lasagna on Friday December 19th.  Many of the manufacturers that we distribute for donated gifts as door prizes and everyone who attended walked away with something.  Signamax came in and did fiber optic demonstration as well as raffling off [...]

Read More »

How Many Boxes of Category 5E fit in a Porsche?

We had a customer come in on Hot Dog Friday (Yes we provide FREE Hot Dogs to all walk-in customers on Fridays) and he had an emergency.  He needed 16 pull boxes of Category 5E to a local location immediately.  He was in his Porsche.  I said no way maybe 12, but he did it.  So [...]

Read More »

What is the difference between a PC Hard Drive and CCTV DVR Hard Drive?

High-Write Workloads While PC data workloads require storage biased for read capability and small-block, random data transfers, video storage must be engineered for writing and large, sequential data blocks. In fact, the writing function can represent up to 95% of a hard drive’s operation in a surveillance application. Furthermore, the always-on nature of most video and surveillance environments intensifies the demands of [...]

Read More »

What distance will my fiber optic cable carry a signal?

Fiber Optic cable will transmit digital data from just 1m to 100's of miles. This chart gives you a rough idea of the distance and the data speeds that are expected from MM 62.5 and MM 50. Category Minimum modal bandwidth 850 nm / 1310 nm  100 Mb Ethernet 100BASE-FX 1 Gb (1000 Mb) Ethernet 1000BASE-SX 10 Gb Ethernet 10GBASE-SR 40 [...]

Read More »

​ How can I make my own HDMI cables?

New from Greenlee is a HDMI Field Installation Kit designed to let the installer make custom length High Speed HDMI cables. The kit includes the stripper, crimper and field installable HDMI plugs allowing the installer to make any custom length HDMI cable from 1’ to 100’.  Check out the video below for installation instructions. This kit allows precise installation of [...]

Read More »

​ Can I get more distance out of Cat 6 vs Cat 5E?

The answer to that questions is no. We have recently had some questions regarding the transmission distance of Cat 5E and Cat 6.  The distance for 10/100/1000 is 100 meters (328 feet) regardless of whether or not it is Cat 5E or Cat 6.The main difference between Cat 5E and Cat 6 is the bandwidth and the crosstalk [...]

Read More »

FXS or FXO Now I’m really confused

FXS is the jack on the wall that provides the dial tone you hook a plain old telephone (POTS) too.FXO is the jack on the phone itself that receives the dial tone.Essentially the FXO and FXS ports were connected in the POTS world.The terms FXS and FXO are used most these days with regards to IP telephony and this [...]
