Honeywell Vista20P Alarm System with 6160RF Wave2 Motion Detector Door Window

Alarm Kit - VISTA20P/6160RFKT-2

Kit Includes:

• 1 - Honeywell VISTA®20P Control Panel - 357-VISTA20P
• 1 - Honeywell 6160RF Integrated Keypad and Receiver - 357-6160RF
• 1 - 12V4.0AH LEAD ACID RECHARGEABLE BATTERY - NT-12/4
• 1 - Honeywell WAVE2 Two-tone Siren - 357-WAVE2
• 1 - Honeywell  5800RES Wireless Motion Detector - 357-5800RES
• 3 - Honeywell 5816 Door/Window Transmitter - 357-5816

The Vista 20P is a professional alarm system.  It is best installed by a qualified alarm technician.  If you are just replacing a damaged system you can replace wire for wire.  If you are not comfortable programming an alarm panel it will not be easy to install. This is the basic kit we can help you customize it for your business or home.  You can add wireless door and window sensors, a Cellular communication interface and much more.

We are a wholesale low voltage distributor.  If you are an alarm professional we would like to work with you.  We have a large in stock inventory that can ship the same day you order.

Here are some items you can add to this systems:
Wireless Motion Detector
Wireless Photoelectric Smoke Detector
Wireless Door/Window Transmitter
CDMA Communicator

Honeywell VISTA®20P Control Panel - 357-VISTA20P

The high capacity, feature-rich VISTA-20P lets you deliver more value to your customers on each and every sale with up to 48 zones of protection, Internet uploading/downloading, graphic keypad support and dual partitions. VISTA-20P gives you the ability to send alarm signals and upload/download via an Internet Protocol (IP), improving the speed at which information can be delivered to and from the control panel. In addition, the VISTA-20P, used with an AlarmNet® Internet or 4G communicator can be installed in premises without TELCO lines. The panel’s installation advantages, innovative end-user benefits and robust system capacity make the value-priced VISTA-20P an ideal choice for higher end installations.

Features:

• IP alarm reporting and uploading/ downloading capability for Internet and Intranet use via iGSMV4G, 7845i-ENT, GSMV4G or GSMX4G
• Supports four graphic touchscreen keypads
• Wireless keys can be programmed without using zones
• Eight on-board hardwired zones standard (15 when Zone Doubling feature is used)
• 40 hardwire expansion zones
• 40 wireless expansion zones
• Two low current on-board trigger outputs
• 100 Event Log viewable at system keypads with time/date stamp
• 48 system user codes assignable to either partition
• Expandable to 48 total zones when used with hardwired and/or wireless expansion modules
• Two independent partitions plus a common partition
• Global Arming from any system keypad
• Go to function to view or operate one partition from the other
• Separate partition account numbers
• 16 output devices
• Relays (Model 4204 Relay Modules, or 4229 Expansion Module)
• Four installer-configurable zone types allows the installer to create custom zone types by assigning all zone attributes
• Supports four-wire and up to 16 two-wire smokes
• Works with Sentrol CleanMe™ maintenance signal
• Multiple actions on output devices depending on system state
• Turns lights off when system arms
• Turns the same light on when system disarms
• Flashes same lights when system is in alarm
• Built-in phone line cut monitor with programmable delay and annunciation options
• Display on system keypads
• Trigger local sounders
• Trigger system bell
• Security Dealer Features
• Automatic System Load Shed
• During extended AC power fail, the system battery will be disconnected to prevent irreversible battery failure. Reduces service calls to replace batteries.
• Dynamic Signaling
• Reduces redundant reporting to the central station when multiple reporting methods are used; i.e. digital dialer and AlarmNet radio
• Valuable End-User Features
• Viewable on system keypads:
• Exit countdown
• Time and date display*
• Event log*
• Auto keypad backlighting on entry
• Keyswitch arming
• Programmable macro buttons and single-button arming
• Supports a variety of wireless remote controls for single-button operation
• User Scheduling
• Latchkey reports to pagers
• Auto arm/disarm
• “User access” time windows
• VIP Module allows system control from any touchtone phone
• Chime by zone
